2" Spacer Lift 2020+ Jeep Gladiator Mojave

2″ Spacer Lift for Gladiator Mojave

$479.00$539.00

Clear
Qty:

Please note: Due to the global microchip shortage, kits are now available with or without a ProCal SNAP – please be aware of which kit you are selecting.

AEV’s 2″ Spacer Lift is the best way for 2020+ Gladiator Mojave owners to add larger tires and improve ground clearance without having to replace any of the performance-tuned OEM suspension components found on these popular vehicles.

All of the components included in the AEV 2″ Spacer Lift have been engineered to integrate seamlessly with the Mojave’s suspension package, for customers who are happy with the overall performance and wish to retain the favorable ride quality and higher-speed damping. The AEV 2″ Spacer Lift includes unique front and rear polyurethane coil spacers with integrated isolators and locating tabs, front and rear bump stop extensions, extended length front and rear sway bar end links, front and rear shock extension brackets and a driveshaft carrier bearing spacer. New Front and Rear Sway Bar End Links have been extended to ensure bind-free functionality.

To make this 2″ Spacer Lift as complete and user friendly as possible, an AEV ProCal SNAP is included for painless speedometer recalibration. ProCal SNAP is a simple, electronic recalibration module that plugs into your vehicle’s OBDII diagnostic port. It utilizes the stereo’s audio equalizer to input the numerical values for your new tire size- saving you time and money by not having to make a trip to the dealership for speedometer recalibration. The AEV ProCal SNAP will also recalibrate for axle gear ratio, transfer case gear ratio changes and TPMS threshold.

The AEV 2″ Spacer Lift is proudly made in the USA and backed by AEV’s Lifetime Warranty.



Please Note: This kit does not fit non-Mojave Gladiators. Non-Mojave Gladiator owners can click here for the correct kit. AEV products are designed, developed and tested specifically to work with other AEV products. Mixing aftermarket or factory components with AEV components may cause interference/tire rubbing at full jounce or full lock. All maximum tire size recommendations are derived from AEV’s product development process using AEV wheels and BFGoodrich tires.

Please note: We will be removing the ProCal from our suspensions temporarily due to supply shortages.

  • Designed specifically for 2020+ Gladiator Mojave
  • Quick, easy installation
  • Retains the Mojave coil springs, shocks and bump stops
  • Accommodates up to a 37″ tall tire*
  • INCLUDES ProCal SNAP for easy speedometer recalibration!
  • AEV Lifetime Warranty
  • Proudly made in the USA



*AEV recommends up to a 37×12.50R17 tire. Aftermarket wheels/wheel spacers are required and minor trimming may also be necessary depending on wheel specs.

Tech Specs:

Kit Contents:
Front Coil Spring Spacers, Front Bump Stop Extensions, Front Shock Extensions, Front Sway Bar End Links, Rear Sway Bar End Links, Rear Coil Spring Spacers, Rear Bump Stop Extensions, Rear Shock Extensions, Rear Coil Spring Spacers, Carrier Bearing Spacer, ProCal SNAP Speedometer Recalibration Module
California Prop 65 Warning

Installation:

Difficulty Level:
Easy
Estimated Install Time:
3-4 Hours
Required Tools:
  • Common Hand Tools
  • Floor Jack
  • Jack Stands

Installation Guides:

AEV30398AE Spacer_JT_noSnap

AEV ProCal Harness for JL Installation Guide

AEV ProCal SNAP for JL & JT User Guide

Product FAQs

Why would I want a spacer lift like this over a full suspension system?

This is an especially good option for Mojave owners who enjoy the OEM performance-tuned suspension package but want to run a larger tire, since the 2" AEV Spacer Lift does interfere with or effect factory suspension's performance. All components of the AEV 2" Spacer Lift integrate seamlessly with the Mojave's performance-tuned coil springs, shock absorbers and jounce bump stops.

Do you have a 2" Spacer Lift for non-Mojave Gladiators?

Yes, the non-Mojave 2" Spacer Lift can be found here: https://www.aev-conversions.com/product/2-spacer-lift-gladiator/

There are a ton of spacer lifts on the market, what makes the AEV Spacer Lift unique?

We paid very close attention to the coil spring spacers themselves. We designed the coil spring spacer to feature an integrated isolator and locating tabs to ensure that the coil spring is properly indexed. Additionally, AEV's Spacer Lift INCLUDES a ProCal SNAP electronic speedometer recalibration module. This easy to use module plugs into the OBD diagnostic port and allows the user to adjust tire size, axle gear ratio and even transfer case gear ratio directly through the vehicle's stereo equalizer! This saves you both time and money, when compared to making a trip to the dealership for a speedometer recalibration. The AEV 2" Spacer Lift is hands-down, the most hassle-free way to add larger tires to your Gladiator.

What is the ProCal SNAP?

The ProCal SNAP is a simple, electronic recalibration module that plugs into your vehicle’s OBDII diagnostic port. It utilizes the stereo’s audio equalizer to input the numerical values for your new tire size- saving you time and money by not having to make a trip to the dealership for speedometer recalibration. The ProCal SNAP also has the ability to recalibrate for axle gear ratio as well as transfer case gear ratio changes.

Do I need to replace my factory shocks?

No! This 2" Spacer Lift works especially well with the Mojave's OEM performance shock package.

What size tire can I fit with the spacer lift?

We recommend up to a 37x12.50R17 on the Mojave. Aftermarket wheels, wheel spacers and/or minor trimming may be necessary depending on what wheel & tire combination you are planning to install on your Wrangler. AEV's JL/Gladiator specific wheels or aftermarket wheels with a similar backspacing/offset are recommended.

Does this fit all trim levels and models?

No, this is specific for the 2020+ Gladiator Mojave.

How many hours will it take me to install this lift? Will I need any special tools?

Installation time is approximately 3-4 hours, with no special tools required. We do recommend using jack stands and a floor jack for safety.

Will your spacer lift give me death wobble?

No but it is good to be aware that due to a host of variables, Gladiators have been known to exhibit tire shimmy (death wobble) and it can be exacerbated by larger tires and tire balance issues. We strongly recommend using quality tires like BFGoodrich or tires of similar/less weight and having them professionally mounted and balanced on quality wheels.

What is the warranty?

The 2" Gladiator Spacer Lift carries AEV's Lifetime Warranty. This covers all of AEV's suspension related components as well as the ProCal SNAP.
