AEV Winch Extension Ropes
$197.00 – $270.00
Adding a winch to your vehicle is one of the most important upgrades anyone who travels to remote locations can make. However, sometimes having just a winch is not enough. This synthetic winch line cable extension rope safely extends the length of your winch’s cable enough to reach your desired recovery or anchor point. If a vehicle recovery involves one or more snatch blocks, you are even more likely to come up short on cable, so keeping an AEV synthetic winch line cable extension rope in your recovery kit ensures that your future recovery efforts will never fall short.
Manufactured out of genuine Dyneema ® SK78 synthetic fiber for maximum strength and durability. AEV Rope Strap included for easy and convenient storage.
|Part Number||Dimensions||Minimum Breaking Strength (MBS)||Working Load Limit (WLL)|
|80808008AA||3/8″x30′||18,200 LBS (8,255 KG)||4,550 LBS (2,065 KG)|
|80808024AA||1/2″x30′||34,300 LBS (15,558 KG)||8,575 LBS (3,889 KG)|
Please Note: Minimum Breaking Strength (MBS) is the minimum force necessary to cause a recovery device to break or fail. Working Load Limit (WLL) is the recommended maximum force a recovery device is intended to safely support, when the force is applied in-line and through the centerline of the device. The WLL is calculated by dividing the Minimum Breaking Strength (MBS) by a safety factor that is generally around 4-to-1. For example, the AEV Snatch Block has an MBS of 52,000 LBS, so when divided by a safety factory of 4-to-1, the WLL becomes 13,000 LBS.
- 1/2" x 30", 3/8" x 30'
- Minimum Breaking Strength (MBS):
- 18,200 LBS (8,255KG) / Full-Size 34,300 LBS (15,558 KG)
- Working Load Limit (WLL):
- 4,550 LBS (2,065 KG) / Full-Size 8,575 LBS (3,889 KG)
- Dyneema® SK78 synthetic fiber
- Black w/ Yellow Ends
- Manufactured In:
